Almond Valley Railway Viaduct
Image taken : 2019-03-27 - 11:51 Fujifilm X-Pro2, XF10-24mm F4 R OIS @ 16.6mm, 1/30sec, f/11, ISO200.
Almond Valley Viaduct is the longest structure on the E&GR main line; it was constructed in a 20-month period. It is in two sections separated by a high embankment about a quarter mile in length. The eastern section consists of 36 ashlar-faced segmental arches of 50 feet span, and the line is on a sweeping curve of about 2,500 yards radius. The spandrels have been strengthened by steel spandrel ties. The western section is of 7 arches, and the centre span bridges the Edinburgh to Bathgate road.
The note above is taken from the Wikipedia article "Edinburgh and Glasgow Railway", which is released under the Creative Commons Attribution-Share-Alike License 3.0.
